Galfan gabion baskets

Gabions is made of double twisted hexagonal woven steel wire mesh, as per ASTM A97597.Gabions are filled with stones at the project site to form flexible, permeable, monolithic structures such as retaining walls, channel linings, and weirs for erosion control projects. Gabion Boxes are wire containers made of hexagonal wire nettings.Wire diameter varies with the hexagonal nettings.

Gabions are environment friendly and cost effective comparing with other options. The advantages of cost and the fact that gabion box can withstand the bad environment for very long time have made the use widespread.
Gabions coated galfan (zinc-5% aluminum-mischmetal [Zn-5 Al-MM] alloy) possess corrosion resistance.However used in polluted, contaminated or aggressive environments: in salt, fresh water,acid soil etc bad environment.It must be superior to electric galvanized and hot dipped galvanized It can used 40-50years in bad environment .Meets the ASTM A 856 / A 856M standard.。

The gabion is divided into cells by diaphragms positioned at approximately 3 ft (0.9 m) centers. To reinforce the structure, all mesh panel edges are selvedged with a wire having a greater diameter.

Galfan gabions offer enhanced durability, and are available upon request. This coating type is the most durable wire coating available internationally and is being increasingly used within Australia to ensure gabion structures achieve a longer design life (2 to 3 times more durable than zinc coatings of the same mass), thereby significantly reducing the life-cycle cost of the structure.

1)Economic. Just fill the stone into the gabions and seal it.
2)Simple installation. No special technology needed.
3)Weather proof under natural destroy, corrosion resistant.
4)Sludge in the stones is good for plant growing. Mixed to form a integrity with the natural environment.
5)Good permeation can prevent the damage by hydrostatic.
6)Less transport freight. It can be folded together for transport and further installation.

Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside areaGalfan 95%(Zinc + 5% Aluminum)gabion

Gabion Sizes Notes
Length(m) Width(m) Height(m) MESH OPENINGS Tolerance
2.00 1.00 0.30 6x8
Length ± 3%
Width ± 5%
Height ± 5%
3.00 1.00 0.30
4.00 1.00 0.30
2.00 1.00 0.50
3.00 1.00 0.50
4.00 1.00 0.50
1.00 1.00 1.00
1.50 1.00 1.00
2.00 1.00 1.00
3.00 1.00 1.00
4.00 1.00 1.00
